The IFS D1000 fiber modem data transceivers provide point-to-point transmission of simplex or duplex EIA RS232/RS-422 data signals over one or two optical fibers. The transceivers are transparent to data encoding allowing for broad-range compatibility. The transceivers are also compatible with the IFS D2100 fiber modem drop and repeat data transceivers when used as line terminating devices. Models within this series are available for use with multimode or singlemode optical fiber. Plug-and-play design ensures ease of installation requiring no electrical or optical adjustments. Each transceiver incorporates power and transmit/receive data status indicating LED’s for monitoring proper system operation. The modules are available in either stand-alone or rack mount versions.

FEATURES

• Meets EIA RS-232/422 Specifications (Simplex or Duplex)

• Meets NEMA TS-1/TS-2 & Caltrans Specifications

• Temperature/Humidity, Shock/Vibration, and Voltage

• Transient Protection)

• Point-to-Point Topology

• Transparent to Data Encoding / Compatible with

• Major Data Protocols

• Data rates up to 1.5 Mbps

• No In-field Electrical or Optical Adjustments Required

• Power, Transmit and Receive Data Status LED Indicators

• NTCIP Compatible

• Tested and Certified by an Independent Testing Laboratory for

• Full Compliance with the Environmental Requirements (Ambient

• Operating Temperature, Mechanical Shock, Vibration, Humidity

• with Condensation, High-Line/Low-Line Voltage Conditions and

• Transient Voltage Protection) of NEMA TS-1/TS-2 and the Caltrans

• Specification for Traffic Signal Control Equipment.

• Integrated WDM for Greater Product Reliability

• Automatic Resettable Solid-State

• Current Limiters

• Hot-Swappable Rack Modules

• Distances up to 37 Miles (60 km)

• Comprehensive Lifetime Warranty
