RS-232 to Fiber Media Converter - Modem

RS232 Fiber modem - Media Converter
RS-232 transmission distance
Up to 2km with multi-mode fiber
Up to 120km with single-mode fiber


- Extends RS-232 transmission distance

- Up to 2km with multi-mode fiber

- Up to 120km with single-mode fiber

- Baud rates up to 230.4Kbps

- External power source supplied

- Compact size


see below for part #


The fiber modem is a low cost, compact, fiber converter designed to extend RS-232 transmissions up to 120Km without any repeaters. The transmissions run in fibers which provide for excellent data security as well as being immune to EMI/RFI, variations in ground potentials, and lightning strikes. With the selectable baud rate, the user can choose its own rate for the transmission. The fiber modem operates at the physical layer (OSI Layer 1) and is completely transparent to the RS-232 transmissions and protocols. The fiber modem may use an external power adapter. Utilizing an ST, SC fiber cable, the fiber modem operates in Full Duplex mode for bi-directional transmissions. The fiber modem RS-232 interface operates in DCE mode for direct connection to DTE devices such as PC DB9 port.









  Part Numbers For Ordering

MM
DECFIB232A-(SC or ST or FC)002
SM
DECFIB232A-(SC or ST or FC) 015 or 030 or 050 or 080 or 120
distance = 015 = 15Km or 030 = 30Km or 050 = 50Km or 080 = 80Km or
120= 120Km
WDM is also available call for part #s
